Series NFM Model NLO-02B

Series NFM Model NLO-02B

Ultra-high power, Long cycle life, Suitable for wide temperature range applications

Suitable for high-rate applications, such as micro electric vehicles, two-wheelers, power tools, start-stop power supplies and other fields.

Main indicators

Performance parameters		Unit	Spec	Typical Value
Particle	D₁₀	μm	＞3.00	4.20
	D₅₀	μm	10.50±3.50	7.90
	D₉₀	μm	＜26.00	13.00
pH		/	≤13.50	12.90
Na₂CO₃		wt%	＜2.00	0.66
NaOH		wt%	＜0.30	0.11
BET		m²/g	0.70±0.20	0.63
CP Density		g/cc	/	3.03
Tap Density		g/cc	1.90±0.30	1.84
Electrode Dencity		g/cc	/	3.00
Coin Cell 2.0-4.0V	0.2C Cha. Cap.	mAh/g	/	143.30
	0.2C Dis. Cap.	mAh/g	130.00±5.00	132.70
	0.2C 1st Eff.	%	≥90.00	92.60

Application Scenarios
