Series NFM Model NLO-03B

Features ultra-high power performance, Long cycle life, Suitable for wide temperature range applications

Suitable for high-rate applications, including micro electric vehicles, electric two-wheelers, power tools, start-stop power supplies and other applications.

Main indicators

Performance parameters		Unit	Spec	Typical Value
Particle	D₁₀	μm	≥2.00	2.92
	D₅₀	μm	11.50±2.50	11.23
	D₉₀	μm	＜26.00	16.85
pH		/	≤13.40	12.73
Na₂CO₃		wt%	＜2.50	1.16
NaOH		wt%	＜0.50	0.19
BET		m²/g	0.55±0.15	0.53
CP Density		g/cc	≥3.15	3.20
Tap Density		g/cc	≥1.50	2.19
Coin Cell 2.0-4.0V	0.2C Cha. Cap.	mAh/g	≥158.90	154.90
	0.2C Dis. Cap.	mAh/g	≥143.00	143.20
	0.2C 1st Eff.	%	≥90.00	92.40

Application Scenarios
